Backpressure in Kafka and NestJS: Protecting Slow Databases and APIs

The production problem

One of the most dangerous Kafka assumptions is:

if lag grows, add more consumers.

That works only if the downstream system can scale too.

Imagine:

Kafka can deliver:        20,000 events/sec
Consumer code can parse:  15,000 events/sec
Database can persist:      3,000 writes/sec

Adding consumers can make the database fail faster.

I use backpressure to keep in-flight work within the sustainable capacity of the slowest dependency.

Bounded concurrency

import pLimit from 'p-limit';

const dbLimit = pLimit(20);

await Promise.all(
  messages.map((message) =>
    dbLimit(
      () => persistEvent(message),
    ),
  ),
);

The number 20 must come from measurements.

If the DB pool has 30 connections, using 100 concurrent writes per consumer instance is obviously unsafe.

Batch insert

For audit/history workloads:

INSERT INTO audit_events (
  event_id,
  aggregate_id,
  event_type,
  payload,
  created_at
)
VALUES
  (?, ?, ?, ?, ?),
  (?, ?, ?, ?, ?),
  (?, ?, ?, ?, ?);

Batching reduces round trips.

But larger batches increase:

• memory;
• retry granularity;
• transaction duration;
• lock time;
• rebalance risk.

I benchmark batch sizes such as 50, 100, 250 rather than assuming the biggest batch wins.

Pause/resume

With KafkaJS-style consumers:

async function guardDownstreamCapacity(
  consumer: Consumer,
  topic: string,
) {
  if (
    dbPool.waitingCount > 50 ||
    memoryQueue.depth() > 500
  ) {
    consumer.pause([{ topic }]);

    await waitUntil(
      () =>
        dbPool.waitingCount < 10 &&
        memoryQueue.depth() < 100,
      30_000,
    );

    consumer.resume([{ topic }]);
  }
}

I prefer pausing the source over creating an unlimited in-memory queue.

Kafka lag is a buffer

A growing lag is not automatically failure.

If the business accepts a ten-minute processing delay during a downstream incident, Kafka is doing exactly what it should: retaining work safely.

I care about:

current lag
oldest event age
processing rate
incoming rate
estimated catch-up time

A useful operational estimate:

catch-up seconds =
backlog /
(processing rate - incoming rate)

If processing rate never exceeds incoming rate after recovery, the backlog will never clear.

Database pool

I monitor:

active connections
idle connections
waiting requests
query p95/p99
transaction time
lock wait
CPU
IOPS

Pool waiting time is often a better early signal than DB CPU alone.

Downstream API backpressure

If a consumer calls an external API limited to 100 RPS:

Kafka
 |
Consumer
 |
token bucket / concurrency limit
 |
External API 100 RPS

More Kafka partitions do not increase provider quota.

Load shedding

For some telemetry workloads, not every event has equal importance.

If business rules allow:

critical audit event -> never drop
high-frequency diagnostic sample -> sample/drop under overload

Load shedding can protect important work.

I make that decision explicit with product/business owners.

Rebalance

Long processing inside one poll can trigger consumer group issues.

I keep work bounded and configure:

session timeout
heartbeat
max poll interval
batch size

to match the processing model.

Production checklist

• Measure downstream sustainable throughput.
• Bound in-flight concurrency.
• Monitor DB pool waiting.
• Use pause/resume before memory explodes.
• Batch only after benchmarking.
• Track oldest event age.
• Calculate backlog recovery time.
• Respect external API quotas.
• Configure consumer heartbeat/poll behavior.
• Load-test recovery from a large backlog.

FAQ

Is consumer lag bad?

Not inherently. It is bad when delay violates SLA or cannot recover.

Should I increase partitions?

Only when downstream work can also scale.

Backpressure or DLQ?

Backpressure handles temporary capacity mismatch. DLQ handles individual messages that cannot be processed successfully.

Related architecture guides

• Transactional Outbox

• Bulkhead Pattern

  Architect's final take

  When input can grow faster than output, the architecture needs a deliberate pressure-release mechanism. Kafka lag is usually safer than a crashed database.
